Details
Applications：
● Phamaceutical industry: tablet, capsule, low sugar or no sugar granule of chinese medicine.
● Foodstuff: cocoa, coffee, milkpowder, juice of granulate, flavoring and so on.
● Other industries: peticide, feed chemical fertilizer, pigment, dyestuff and so on.
● Pharmaceutical industry: tablet.
Principle：
The powder grannle in the container (fluidization)appear in the state of fluidization. It is preheated and mixed with chen and heated air. At the same time the solution of adhesive solvent is fogged and sprayed into the container. It makes the some particles become granulating that contains adhesive. Being of unceasing dry through hot air, the moisture in the granulation is evaporated and the adhesive is solidification. The process is carried out continuously. Finally it forms ideal, uniform and Porous granules.
Features：
● Because of powder Granulation, the fluidity is improved and the dust is reduced;
● Because of powder Granulation, its solving property is improved;
● The mixing, Granulation and drying can be completed in one step inside the machine;
● The operation of equipment is safe because the anti static filtering cloth is adapted;
● The operating personnel can not be damaged if explosion take place because there is releasing hole;
● The equipment has no dead corner. Therefore the loading and unloading are quick and light and clean. It can meet the requirements of GMP.
|
Item Unit Model 3 5 15 30 60 120 200 300 500 |
|||||||||||
| Container of raw material | Volume | L | 12 | 22 | 45 | 100 | 220 | 420 | 670 | 1000 | 1500 |
| 直Diamter | mm | 300 | 400 | 550 | 700 | 1000 | 1200 | 1400 | 1600 | 1800 | |
| Production capacity | Min | Kg | 1.5 | 4 | 10 | 15 | 30 | 80 | 100 | 150 | 250 |
| Max | Kg | 4.5 | 6 | 20 | 45 | 90 | 160 | 300 | 450 | 750 | |
| Fan | Air volume | m3/h | 1000 | 1200 | 1400 | 1800 | 3000 | 4500 | 6000 | 7000 | 8000 |
| Air pressure | mmHO | 375 | 375 | 480 | 480 | 950 | 950 | 950 | 950 | 950 | |
| Power | Kw | 3 | 4 | 5.5 | 7.5 | 11 | 18.5 | 22 | 30 | 45 | |
| Steam consumption | Kg/h | 15 | 23 | 42 | 70 | 141 | 211 | 282 | 366 | 451 | |
| Amount of compressed air | m3/min | 0.9 | 0.9 | 0.9 | 0.9 | 1.0 | 1.0 | 1.1 | 1.5 | 1.5 | |
| Weight | Kg | 500 | 700 | 900 | 1000 | 1100 | 1300 | 1500 | 1800 | 2000 | |
| Pressure of steam | Mpa | 0.3~0.6 | |||||||||
| Temperature | ℃ | Adjustable at the range from room temperature to 120℃ | |||||||||
| Operation time | min | 45-90 Decided in accordance with the properities of raw material | |||||||||
| Yield | ﹪ | ≥99 | |||||||||
| Noise | dB(A) | When installation,main machine is seperated from fan. ≤75 dB(A) | |||||||||
| Overall dimension L×W×H | m | 1.0×0.6×2.1 | 1.2×0.7×2.1 | 1.25×0.9×2.5 | 1.6×1.1×2.5 | 1.85×1.4×3 | 2.2×1.65×3.3 | 2.34×1.7×3. | |||
